AIA NASM33537

INSERT, SCREW THREAD, HELICAL COIL, INCH SERIES, COARSE AND FINE THREAD, STANDARD ASSEMBLY DIMENSIONS FOR

Aerospace Industries Association , 01/31/2017

Publisher: AIA

File Format: PDF

$34.00$69.00

Description

Standard By:Aerospace Industries Association , 01/31/2017

Published:01/31/2017

Pages:14

File Size:1 file , 240 KB

Language:English

DESCRIPTION

Helical coil inserts are screw thread bushings coiled from diamond shaped cross-section wire. They are screwed into tapped holes to form nominal size internal threads. Inserts are installed by torquing through a diametral tang which is notched for tang removal.
