IEC 60076-7 Ed. 2.0 en:2018

Power transformers - Part 7: Loading guide for mineral-oil-immersed power transformers

International Electrotechnical Commission , 01/12/2018

Publisher: IEC

File Format: PDF

$208.00$417.00


IEC 60076-7:2018 RLV contains the International Standard and its Redline version. The Redline version is available in English only. The Redline version provides you with a quick and easy way to compare all the changes between this standard and its previous edition. The Redline version is not an official IEC Standard, only the current version of the standard is to be considered the official document.

IEC 60076-7:2018 is applicable to mineral-oil-immersed transformers. It describes the effect of operation under various ambient temperatures and load conditions on transformer life. This document provides guidance for the specification and loading of power transformers from the point of view of operating temperatures and thermal ageing. It provides recommendations for loading above the nameplate rating and guidance for the planner to choose appropriate rated quantities and loading conditions for new installations. This edition includes the following significant technical changes with respect to the previous edition:
a) title has been updated from "oil-immersed power transformers" to "mineral-oil-immersed transformers";
b) insulation life is updated by considering latest research findings;
c) temperature limits have been reviewed and maximum core temperature is recommended;
d) number of fibre optic sensors is recommended for temperature rise test;
e) Q, S and H factors are considered;
f) thermal models are revised and rewritten in generally applicable mathematical form;
g) geomagnetic induced currents are briefly discussed and corresponding temperature limits are suggested;
h) extensive literature review has been performed and a number of references added to bibliography.

IEC 60076-7 Ed. 2.0 en:2018 History

IEC 60076-7 Ed. 2.0 en:2018

IEC 60076-7 Ed. 2.0 en:2018

$208.00 $417.00

IEC 60076-7 Ed. 1.0 b:2005

IEC 60076-7 Ed. 1.0 b:2005

$158.00 $317.00
