IEC 60191-6-13 Ed. 2.0 b:2016

Mechanical standardization of semiconductor devices - Part 6-13: Design guideline of open-top-type sockets for Fine-pitch Ball Grid Array (FBGA) and Fine-pitch Land Grid Array (FLGA)

International Electrotechnical Commission , 09/27/2016

Publisher: IEC

File Format: PDF

$72.00$145.00


IEC 60191-6-13:2016 specifies a design guideline of open-top-type semiconductor sockets for Fine-pitch Ball Grid Array (FBGA) and Fine-pitch Land Grid Array (FLGA). In particular, this part of IEC 60191 establishes the outline drawings and dimensions of the open-top-type test and burn-in sockets applied to FBGA and FLGA. This edition includes the following significant technical changes with respect to the previous edition:
a) BGA package nominal length and width have been newly expanded to 43 mm and 43 mm, respectively. Accordingly, six socket sizes have been added to the socket group numbers 1, 2 and 3, and twenty-two socket sizes have been added to the socket group number 4.

IEC 60191-6-13 Ed. 2.0 b:2016 History

IEC 60191-6-13 Ed. 2.0 b:2016
IEC 60191-6-13 Ed. 1.0 b:2007
IEC 60191-6-13 Ed. 1.0 en:2007
