• IEC 60191-6-8 Ed. 1.0 b:2001

IEC 60191-6-8 Ed. 1.0 b:2001

Mechanical standardization of semiconductor devices - Part 6-8: General rules for the preparation of outline drawings of surface mounted semiconductor device packages - Design guide for glass sealed ceramic quad flatpack (G-QFP)

International Electrotechnical Commission , 08/27/2001

Publisher: IEC

File Format: PDF

$25.00$51.00


IEC 60191-6-8:2001 provides the common outline drawings and dimensions for all types of structures and composed materials of glass sealed ceramic quad flatpack (hereinafter called G-QFP). The object of this design guide is to standardize outlines and obtain interchangeability of G-QFP.

IEC 60191-6-8 Ed. 1.0 b:2001 History

IEC 60191-6-8 Ed. 1.0 en:2001
IEC 60191-6-8 Ed. 1.0 b:2001
