IEC 61076-2-101 Ed. 2.0 b:2008

Connectors for electronic equipment - Product requirements - Part 2-101: Circular connectors - Detail specification for M12 connectors with screw-locking

International Electrotechnical Commission , 07/09/2008

Publisher: IEC

File Format: PDF

$121.00$243.00

Description

Standard By:International Electrotechnical Commission , 07/09/2008

Published:07/09/2008

Pages:109

File Size:1 file , 3.1 MB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

IEC 61076-2-101:2008 describes circular connectors M12 typically used for industrial process measurement and control. These connectors consist of fixed and free connectors with screw-locking. Male connectors have round contacts of diameters 0,6 mm, 0,76 mm, 0,8 mm and 1,0 mm. This new edition includes the following significant technical change with respect to the previous edition: the connector type M8 has been removed from IEC 61076-2-101 and has been published in a separate IEC Standard under reference IEC 61076-2-104.
