IEC 61076-8-105 Ed. 1.0 b:2023

Connectors for electrical and electronic equipment – Product requirements – Part 8-105: Power connectors – Detail specification for 2-pole snap locking rectangular power connectors with plastic housing for 63 A rated current and 400 V rated voltage

International Electrotechnical Commission , 08/01/2023

Publisher: IEC

File Format: PDF

$117.00$234.00

Description

Standard By:International Electrotechnical Commission , 08/01/2023

Published:08/01/2023

Pages:64

ISBN(s):9782832272091

File Size:1 file , 1.5 MB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

This part of IEC 61076-8 applies to free and fixed 2-pole snap locking rectangular power connectors with plastic housing with rated current 63 A and rated voltage up to 400 V. It includes overall dimensions, interface dimensions, technical characteristics, performance requirements, test methods.

The products covered by this detail specification are connectors without breaking capacity (COC) according to IEC 61984 and are mainly deemed to be used in AC power feeding of class II equipment (hence no PE contact provided), in the field of electrical and electronic equipment.

IEC 61076-8-105 Ed. 1.0 b:2023

Connectors for electrical and electronic equipment – Product requirements – Part 8-105: Power connectors – Detail specification for 2-pole snap locking rectangular power connectors with plastic housing for 63 A rated current and 400 V rated voltage
