IEC 61169-64 Ed. 1.0 b:2019

Radio frequency connectors - Part 64: Sectional specification - RF coaxial connectors with 0,8 mm inner diameter of outer conductor - Characteristic impedance 50 Omega (type 0,8)

International Electrotechnical Commission , 09/12/2019

Publisher: IEC

File Format: PDF

$95.00$190.00

Description

Standard By:International Electrotechnical Commission , 09/12/2019

Published:09/12/2019

Pages:45

File Size:1 file , 2.1 MB

Language:English, French

Note:This product is unavailable in Ukraine, Russia, Belarus

IEC 61169-64:2019, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for IEC 61169 (all parts) coaxial connectors with 0,8 mm coupling.

The connectors are used with cables with characteristic impedance 50 Ώ in an operating frequency range up to 145 GHz. The connectors are widely used in communications and measurements.

It describes the interface dimensions for general purpose connectors with gauging information and the mandatory tests selected from IEC 61169-1, applicable to all detail specifications relative to type 0,8 connectors.

This specification indicates the recommended performance characteristics to be considered when writing a DS and covers all tests schedules and inspection requirements.
