TIA TIA-1099-A

Scope of This Document

These technical requirements form a compatibility standard for Forward Link Only multimedia multicast systems. These requirements ensure that a compliant Forward Link Only device can obtain service through any Forward Link Only network conforming to this standard.

Revision A of this specification provides support for extending the operation of Forward Link Only systems to a frequency range wider than the UHF band. In addition, the Positioning Pilot Channel is specified to allow for the identification of individual transmitters operating on the same or different carrier center frequencies. A new control protocol message is also added to support the extended frequency range and to enhance operation in networks with multiple carrier center frequencies.

Specifically, Revision A includes the following:

• A new Extended Neighbor List Description Message that replaces the Neighbor List 26 Description and RF Channel Description Messages.

• FFT sizes of 1024, 2048 and 8192 in addition to the value of 4096.

• Flat guard interval fractions of 1/16, 3/16 and 1/4 in addition to the value of 1/8.

• Addition of a new pilot pattern and slot to interlace mapping.

• A new Signaling Parameter Channel to convey the FFT size, flat guard interval 31 fraction and slot to interlace mapping.

• An updated specification for the Positioning Pilot Channel.
